AM5T-4805S-VZ

Technical Details

• Series:AM5T-VZ (5W)
• Package:Tube
• Part Status:Active
• Type:Isolated Module
• Number of Outputs:1
• Voltage - Input (Min):36V
• Voltage - Input (Max):72V
• Voltage - Output 1:5V
• Voltage - Output 2:-
• Voltage - Output 3:-
• Voltage - Output 4:-
• Current - Output (Max):1A
• Power (Watts):5 W

• Voltage - Isolation:1.5 kV
• Applications:ITE (Commercial)
• Features:-
• Operating Temperature:-40°C ~ 85°C
• Efficiency:77%
• Mounting Type:Through Hole
• Package / Case:24-DIP Module, 7 Leads
• Size / Dimension:1.27" L x 0.84" W x 0.41" H (32.3mm x 21.4mm x 10.5mm)
• Supplier Device Package:-
• Control Features:-
• Approval Agency:-
• Standard Number:-
