AM2GW-2412SZ

Technical Details

• Series:AM2GW-Z (2W)
• Package:Tube
• Part Status:Active
• Type:Isolated Module
• Number of Outputs:1
• Voltage - Input (Min):9V
• Voltage - Input (Max):36V
• Voltage - Output 1:12V
• Voltage - Output 2:-
• Voltage - Output 3:-
• Voltage - Output 4:-
• Current - Output (Max):165mA
• Power (Watts):2 W

• Voltage - Isolation:1.5 kV
• Applications:ITE (Commercial)
• Features:Remote On/Off
• Operating Temperature:-40°C ~ 85°C (With Derating)
• Efficiency:84%
• Mounting Type:Through Hole
• Package / Case:9-SIP Module, 7 Leads
• Size / Dimension:1.02" L x 0.37" W x 0.49" H (26.0mm x 9.3mm x 12.5mm)
• Supplier Device Package:-
• Control Features:-
• Approval Agency:CE, cURus, UL
• Standard Number:-
