AM10T-1212DNZ
DComponents
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionDC DC CONVERTER 12V -12V 10W
- CategoryDC DC Converters
-
ECAD Model
- Share
In Stock: 152
Can ship immediately
Pricing:
- 1$15.4
Quote It
Technical Details
- Series:AM10T-NZ (10W)
- Package:Tube
- Part Status:Active
- Type:Isolated Module
- Number of Outputs:2
- Voltage - Input (Min):9V
- Voltage - Input (Max):18V
- Voltage - Output 1:12V
- Voltage - Output 2:-12V
- Voltage - Output 3:-
- Voltage - Output 4:-
- Current - Output (Max):416mA, 416mA
- Power (Watts):10 W
- Voltage - Isolation:1.5 kV
- Applications:ITE (Commercial)
- Features:Remote On/Off
- Operating Temperature:-40°C ~ 71°C (With Derating)
- Efficiency:87%
- Mounting Type:Through Hole
- Package / Case:24-DIP Module, 9 Leads
- Size / Dimension:1.26" L x 10.78" W x 0.42" H (32.0mm x 20.0mm x 10.8mm)
- Supplier Device Package:-
- Control Features:-
- Approval Agency:-
- Standard Number:-
