REC3-1215DR/H1

Technical Details

• Series:ECONOLINE REC3-DR (3W)
• Package:Tube
• Part Status:Active
• Type:Isolated Module
• Number of Outputs:2
• Voltage - Input (Min):10.8V
• Voltage - Input (Max):13.2V
• Voltage - Output 1:15V
• Voltage - Output 2:-15V
• Voltage - Output 3:-
• Voltage - Output 4:-
• Current - Output (Max):100mA, 100mA
• Power (Watts):3 W

• Voltage - Isolation:1 kV
• Applications:ITE (Commercial)
• Features:SCP
• Operating Temperature:-40°C ~ 80°C
• Efficiency:75%
• Mounting Type:Through Hole
• Package / Case:24-DIP Module, 12 Leads
• Size / Dimension:1.26" L x 0.80" W x 0.40" H (32.0mm x 20.3mm x 10.2mm)
• Supplier Device Package:-
• Control Features:-
• Approval Agency:-
• Standard Number:-
