MGXW1R52415

Technical Details

• Series:MGX (1.5W)
• Package:Tube
• Part Status:Active
• Type:Isolated Module
• Number of Outputs:2
• Voltage - Input (Min):6V
• Voltage - Input (Max):60V
• Voltage - Output 1:15V
• Voltage - Output 2:-15V
• Voltage - Output 3:-
• Voltage - Output 4:-
• Current - Output (Max):50mA, 50mA
• Power (Watts):1.5 W

• Voltage - Isolation:1.5 kV
• Applications:ITE (Commercial)
• Features:-
• Operating Temperature:-40°C ~ 85°C (With Derating)
• Efficiency:80%
• Mounting Type:Through Hole
• Package / Case:6-SIP Module, 5 Leads
• Size / Dimension:0.67" L x 0.33" W x 0.47" H (17.0mm x 8.5mm x 12.0mm)
• Supplier Device Package:-
• Control Features:-
• Approval Agency:CE, cURus, DEMKO
• Standard Number:-
