JCE0324D03-H
XP Power
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionDC DC CONVERTER +/-3.3V 3W
- CategoryDC DC Converters
- Datasheet JCE0324D03-H Datasheet
-
ECAD Model
- Share
In Stock: 144
Can ship immediately
Pricing:
- 1$16.215
- 10$16.215
Quote It
Technical Details
- Series:JCE (3W)
- Package:Tube
- Part Status:Active
- Type:Isolated Module
- Number of Outputs:2
- Voltage - Input (Min):18V
- Voltage - Input (Max):36V
- Voltage - Output 1:3.3V
- Voltage - Output 2:-3.3V
- Voltage - Output 3:-
- Voltage - Output 4:-
- Current - Output (Max):450mA, 450mA
- Power (Watts):3 W
- Voltage - Isolation:3 kV
- Applications:ITE (Commercial)
- Features:SCP
- Operating Temperature:-40°C ~ 100°C
- Efficiency:75%
- Mounting Type:Through Hole
- Package / Case:24-DIP Module, 7 Leads
- Size / Dimension:1.25" L x 0.80" W x 0.40" H (31.8mm x 20.3mm x 10.2mm)
- Supplier Device Package:-
- Control Features:-
- Approval Agency:-
- Standard Number:62368-1
