RW2-0509D/B

Technical Details

• Series:ECONOLINE RW2 (2W)
• Package:Tube
• Part Status:Active
• Type:Isolated Module
• Number of Outputs:2
• Voltage - Input (Min):4.5V
• Voltage - Input (Max):9V
• Voltage - Output 1:9V
• Voltage - Output 2:-9V
• Voltage - Output 3:-
• Voltage - Output 4:-
• Current - Output (Max):111mA, 111mA
• Power (Watts):2 W

• Voltage - Isolation:1 kV
• Applications:ITE (Commercial), Medical
• Features:SCP
• Operating Temperature:-40°C ~ 85°C
• Efficiency:74%
• Mounting Type:Through Hole
• Package / Case:16-DIP Module, 6 Leads
• Size / Dimension:0.87" L x 0.49" W x 0.33" H (22.1mm x 12.6mm x 8.5mm)
• Supplier Device Package:-
• Control Features:-
• Approval Agency:-
• Standard Number:-
