3D8W4_1205S1.6RP

Technical Details

• Series:3D8W4_1.6RP (3W)
• Package:Tube
• Part Status:Active
• Type:Isolated Module
• Number of Outputs:1
• Voltage - Input (Min):4.5V
• Voltage - Input (Max):18V
• Voltage - Output 1:5V
• Voltage - Output 2:-
• Voltage - Output 3:-
• Voltage - Output 4:-
• Current - Output (Max):600mA
• Power (Watts):3 W

• Voltage - Isolation:1.6 kV
• Applications:ITE (Commercial)
• Features:Remote On/Off
• Operating Temperature:-40°C ~ 80°C (With Derating)
• Efficiency:81%
• Mounting Type:Through Hole
• Package / Case:8-DIP Module, 5 Leads
• Size / Dimension:0.55" L x 0.55" W x 0.32" H (14.0mm x 14.0mm x 8.1mm)
• Supplier Device Package:-
• Control Features:-
• Approval Agency:CE
• Standard Number:-
