PQDE6W-Q110-S5-H-D

Technical Details

• Series:PQDE6W-Q110 (6W)
• Package:Tube
• Part Status:Active
• Type:Isolated Module
• Number of Outputs:1
• Voltage - Input (Min):40V
• Voltage - Input (Max):160V
• Voltage - Output 1:5V
• Voltage - Output 2:-
• Voltage - Output 3:-
• Voltage - Output 4:-
• Current - Output (Max):1.2A
• Power (Watts):6 W

• Voltage - Isolation:2.25 kV
• Applications:ITE (Commercial)
• Features:Heat Sink
• Operating Temperature:-40°C ~ 85°C (With Derating)
• Efficiency:80%
• Mounting Type:Through Hole
• Package / Case:6-DIP Module, 4 Leads
• Size / Dimension:1.00" L x 1.00" W x 0.64" H (25.4mm x 25.4mm x 16.2mm)
• Supplier Device Package:-
• Control Features:-
• Approval Agency:CE
• Standard Number:-
