RS-1205D/H2
RECOM Power
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionDC DC CONVERTER +/-5V 2W
- CategoryDC DC Converters
- Datasheet RS-1205D/H2 Datasheet
-
ECAD Model
- Share
In Stock: 111
Can ship immediately
Pricing:
- 1$17.17818
- 22$17.17818
Quote It
Technical Details
- Series:ECONOLINE RS (2W)
- Package:Tube
- Part Status:Active
- Type:Isolated Module
- Number of Outputs:2
- Voltage - Input (Min):9V
- Voltage - Input (Max):18V
- Voltage - Output 1:5V
- Voltage - Output 2:-5V
- Voltage - Output 3:-
- Voltage - Output 4:-
- Current - Output (Max):200mA, 200mA
- Power (Watts):2 W
- Voltage - Isolation:2 kV
- Applications:ITE (Commercial), Medical
- Features:Remote On/Off, SCP
- Operating Temperature:-40°C ~ 85°C
- Efficiency:75%
- Mounting Type:Through Hole
- Package / Case:8-SIP Module, 7 Leads
- Size / Dimension:0.86" L x 0.36" W x 0.44" H (21.8mm x 9.2mm x 11.1mm)
- Supplier Device Package:-
- Control Features:Enable, Active Low
- Approval Agency:-
- Standard Number:-
