JCD0548D09

Technical Details

• Series:JCD (5W)
• Package:Tube
• Part Status:Active
• Type:Isolated Module
• Number of Outputs:2
• Voltage - Input (Min):36V
• Voltage - Input (Max):72V
• Voltage - Output 1:9V
• Voltage - Output 2:-9V
• Voltage - Output 3:-
• Voltage - Output 4:-
• Current - Output (Max):278mA
• Power (Watts):5 W

• Voltage - Isolation:1.6 kV
• Applications:ITE (Commercial)
• Features:OCP, OVP, SCP
• Operating Temperature:-40°C ~ 100°C
• Efficiency:82%
• Mounting Type:Through Hole
• Package / Case:24-DIP Module, 8 Leads
• Size / Dimension:1.25" L x 0.80" W x 0.41" H (31.8mm x 20.3mm x 10.4mm)
• Supplier Device Package:-
• Control Features:-
• Approval Agency:-
• Standard Number:62368-1
