R24P23.3S/P/X2/R8

Technical Details

• Series:ECONOLINE RxxP2xx/R (2W)
• Package:Tube
• Part Status:Active
• Type:Isolated Module
• Number of Outputs:1
• Voltage - Input (Min):21.6V
• Voltage - Input (Max):26.4V
• Voltage - Output 1:3.3V
• Voltage - Output 2:-
• Voltage - Output 3:-
• Voltage - Output 4:-
• Current - Output (Max):600mA
• Power (Watts):2 W

• Voltage - Isolation:8 kV
• Applications:ITE (Commercial), Medical
• Features:SCP
• Operating Temperature:-40°C ~ 85°C
• Efficiency:78%
• Mounting Type:Through Hole
• Package / Case:7-SIP Module, 4 Leads
• Size / Dimension:0.77" L x 0.39" W x 0.49" H (19.5mm x 9.8mm x 12.5mm)
• Supplier Device Package:-
• Control Features:-
• Approval Agency:-
• Standard Number:-
