R-525.0PA

Technical Details

• Series:INNOLINE R-5xxxA
• Package:Tube
• Part Status:Active
• Type:Non-Isolated PoL Module
• Number of Outputs:1
• Voltage - Input (Min):6.5V
• Voltage - Input (Max):18V
• Voltage - Output 1:5V
• Voltage - Output 2:-
• Voltage - Output 3:-
• Voltage - Output 4:-
• Current - Output (Max):2A
• Power (Watts):10 W

• Voltage - Isolation:-
• Applications:ITE (Commercial)
• Features:Remote On/Off, OCP, SCP
• Operating Temperature:-40°C ~ 85°C
• Efficiency:95%
• Mounting Type:Through Hole
• Package / Case:12-SIP Module
• Size / Dimension:1.27" L x 0.36" W x 0.59" H (32.2mm x 9.1mm x 15.0mm)
• Supplier Device Package:-
• Control Features:Enable, Active High
• Approval Agency:-
• Standard Number:-
