JTF1224D05
XP Power
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionDC DC CONVERTER +/-5V 12W
- CategoryDC DC Converters
- Datasheet JTF1224D05 Datasheet
-
ECAD Model
- Share
In Stock: 177
Can ship immediately
Pricing:
- 1$29.14
- 5$28.2658
- 10$27.3916
- 25$26.226
- 100$24.6233
Quote It
Technical Details
- Series:JTF (15W)
- Package:Tube
- Part Status:Active
- Type:Isolated Module
- Number of Outputs:2
- Voltage - Input (Min):9V
- Voltage - Input (Max):36V
- Voltage - Output 1:5V
- Voltage - Output 2:-5V
- Voltage - Output 3:-
- Voltage - Output 4:-
- Current - Output (Max):1.2A, 1.2A
- Power (Watts):12 W
- Voltage - Isolation:1.6 kV
- Applications:ITE (Commercial)
- Features:Remote On/Off, OCP, OVP, SCP
- Operating Temperature:-40°C ~ 105°C
- Efficiency:87%
- Mounting Type:Through Hole
- Package / Case:24-DIP Module, 9 Leads
- Size / Dimension:1.25" L x 0.80" W x 0.40" H (31.8mm x 20.3mm x 10.2mm)
- Supplier Device Package:-
- Control Features:Enable, Active High
- Approval Agency:-
- Standard Number:62368-1
