20DMW4_4812D1.5

Technical Details

• Series:20DMW4_1.5 (20W)
• Package:Tube
• Part Status:Active
• Type:Isolated Module
• Number of Outputs:2
• Voltage - Input (Min):18V
• Voltage - Input (Max):75V
• Voltage - Output 1:12V
• Voltage - Output 2:-12V
• Voltage - Output 3:-
• Voltage - Output 4:-
• Current - Output (Max):833mA, 833mA
• Power (Watts):20 W

• Voltage - Isolation:1.5 kV
• Applications:ITE (Commercial)
• Features:Adjustable Output, Baseplate, Remote On/Off
• Operating Temperature:-40°C ~ 85°C (With Derating)
• Efficiency:89%
• Mounting Type:Through Hole
• Package / Case:6-DIP Module
• Size / Dimension:1.00" L x 1.00" W x 0.40" H (25.4mm x 25.4mm x 10.1mm)
• Supplier Device Package:-
• Control Features:-
• Approval Agency:-
• Standard Number:60950-1
