RP08-4812DAW

Technical Details

• Series:POWERLINE RP08-W (8W)
• Package:Tube
• Part Status:Active
• Type:Isolated Module
• Number of Outputs:2
• Voltage - Input (Min):18V
• Voltage - Input (Max):75V
• Voltage - Output 1:12V
• Voltage - Output 2:-12V
• Voltage - Output 3:-
• Voltage - Output 4:-
• Current - Output (Max):333mA, 333mA
• Power (Watts):8 W

• Voltage - Isolation:1.6 kV
• Applications:ITE (Commercial), Railway
• Features:Remote On/Off, OCP, OVP, SCP
• Operating Temperature:-40°C ~ 85°C
• Efficiency:87%
• Mounting Type:Through Hole
• Package / Case:24-DIP Module, 9 Leads
• Size / Dimension:1.25" L x 0.80" W x 0.40" H (31.8mm x 20.3mm x 10.2mm)
• Supplier Device Package:-
• Control Features:Enable, Active High
• Approval Agency:-
• Standard Number:-
