AM30K-4805SZ-K

Technical Details

• Series:AM30K-Z (30W)
• Package:Tube
• Part Status:Active
• Type:Isolated Module
• Number of Outputs:1
• Voltage - Input (Min):36V
• Voltage - Input (Max):75V
• Voltage - Output 1:5V
• Voltage - Output 2:-
• Voltage - Output 3:-
• Voltage - Output 4:-
• Current - Output (Max):5A
• Power (Watts):25 W

• Voltage - Isolation:1.5 kV
• Applications:ITE (Commercial)
• Features:Adjustable Output, Heat Sink, Remote On/Off
• Operating Temperature:-40°C ~ 70°C (With Derating)
• Efficiency:87%
• Mounting Type:Through Hole
• Package / Case:7-DIP Module, 6 Leads
• Size / Dimension:2.00" L x 1.60" W x 0.64" H (50.8mm x 40.6mm x 16.3mm)
• Supplier Device Package:-
• Control Features:-
• Approval Agency:CE
• Standard Number:-
