REC6-1215DRW/R10/A/CTRL/X1

Technical Details

• Series:ECONOLINE REC6/R (6W)
• Package:Tube
• Part Status:Active
• Type:Isolated Module
• Number of Outputs:2
• Voltage - Input (Min):9V
• Voltage - Input (Max):18V
• Voltage - Output 1:15V
• Voltage - Output 2:-15V
• Voltage - Output 3:-
• Voltage - Output 4:-
• Current - Output (Max):200mA, 200mA
• Power (Watts):6 W

• Voltage - Isolation:10 kV
• Applications:ITE (Commercial), Medical
• Features:Remote On/Off, SCP, UVLO
• Operating Temperature:-40°C ~ 75°C
• Efficiency:82%
• Mounting Type:Through Hole
• Package / Case:24-DIP Module, 7 Leads
• Size / Dimension:1.26" L x 0.80" W x 0.40" H (32.0mm x 20.3mm x 10.2mm)
• Supplier Device Package:-
• Control Features:Enable, Active Low
• Approval Agency:-
• Standard Number:-
