RP15-2405DAW

Technical Details

• Series:POWERLINE RP15-AW (15W)
• Package:Tube
• Part Status:Active
• Type:Isolated Module
• Number of Outputs:2
• Voltage - Input (Min):9V
• Voltage - Input (Max):36V
• Voltage - Output 1:5V
• Voltage - Output 2:-5V
• Voltage - Output 3:-
• Voltage - Output 4:-
• Current - Output (Max):1.5A, 1.5A
• Power (Watts):15 W

• Voltage - Isolation:1.6 kV
• Applications:ITE (Commercial)
• Features:OCP, OVP, SCP
• Operating Temperature:-40°C ~ 85°C
• Efficiency:85%
• Mounting Type:Through Hole
• Package / Case:6-DIP Module, 5 Leads
• Size / Dimension:1.00" L x 1.00" W x 0.39" H (25.4mm x 25.4mm x 9.9mm)
• Supplier Device Package:-
• Control Features:-
• Approval Agency:-
• Standard Number:-
