PXG-M15-24WS24

Technical Details

• Series:PXG-M (20W)
• Package:Tube
• Part Status:Active
• Type:Isolated Module
• Number of Outputs:1
• Voltage - Input (Min):9V
• Voltage - Input (Max):36V
• Voltage - Output 1:24V
• Voltage - Output 2:-
• Voltage - Output 3:-
• Voltage - Output 4:-
• Current - Output (Max):625mA
• Power (Watts):15 W

• Voltage - Isolation:5 kV
• Applications:ITE (Commercial), Medical
• Features:Adjustable Output
• Operating Temperature:-40°C ~ 105°C (With Derating)
• Efficiency:88%
• Mounting Type:Through Hole
• Package / Case:6-DIP Module
• Size / Dimension:1.60" L x 1.00" W x 0.40" H (40.6mm x 25.4mm x 10.2mm)
• Supplier Device Package:-
• Control Features:-
• Approval Agency:CE
• Standard Number:-
