AM60U-4805SZ-K

Technical Details

• Series:AM60U-Z (60W)
• Package:Tube
• Part Status:Active
• Type:Isolated Module
• Number of Outputs:1
• Voltage - Input (Min):36V
• Voltage - Input (Max):75V
• Voltage - Output 1:5V
• Voltage - Output 2:-
• Voltage - Output 3:-
• Voltage - Output 4:-
• Current - Output (Max):12A
• Power (Watts):60 W

• Voltage - Isolation:1.6 kV
• Applications:ITE (Commercial)
• Features:Heat Sink, Remote On/Off
• Operating Temperature:-40°C ~ 85°C (With Derating)
• Efficiency:91%
• Mounting Type:Through Hole
• Package / Case:8-DIP Module
• Size / Dimension:2.00" L x 2.00" W x 0.64" H (50.8mm x 50.8mm x 16.3mm)
• Supplier Device Package:-
• Control Features:-
• Approval Agency:-
• Standard Number:-
