JCK5012S15
XP Power
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionDC DC CONVERTER 15V 50W
- CategoryDC DC Converters
- Datasheet JCK5012S15 Datasheet
-
ECAD Model
- Share
In Stock: 189
Can ship immediately
Pricing:
- 1$80
- 5$77.6
- 10$75.2
- 25$72
- 100$67.2005
Quote It
Technical Details
- Series:JCK50 (50W)
- Package:Tube
- Part Status:Active
- Type:Isolated Module
- Number of Outputs:1
- Voltage - Input (Min):9V
- Voltage - Input (Max):18V
- Voltage - Output 1:15V
- Voltage - Output 2:-
- Voltage - Output 3:-
- Voltage - Output 4:-
- Current - Output (Max):3.33A
- Power (Watts):50 W
- Voltage - Isolation:1.6 kV
- Applications:ITE (Commercial)
- Features:Remote On/Off, OCP, SCP
- Operating Temperature:-40°C ~ 95°C (With Derating)
- Efficiency:89%
- Mounting Type:Through Hole
- Package / Case:6-DIP Module
- Size / Dimension:2.00" L x 1.00" W x 0.45" H (50.8mm x 25.4mm x 11.4mm)
- Supplier Device Package:6-DIP
- Control Features:-
- Approval Agency:-
- Standard Number:62368-1
