AM100QB-2448SH22-NZ-192
DComponents
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionDC DC CONVERTER 48V 101W
- CategoryDC DC Converters
-
ECAD Model
- Share
In Stock: 109
Can ship immediately
Pricing:
- 1$92.28
Quote It
Technical Details
- Series:AM100QB-NZ (100W)
- Package:Box
- Part Status:Active
- Type:Isolated Module
- Number of Outputs:1
- Voltage - Input (Min):9V
- Voltage - Input (Max):36V
- Voltage - Output 1:48V
- Voltage - Output 2:-
- Voltage - Output 3:-
- Voltage - Output 4:-
- Current - Output (Max):2.1A
- Power (Watts):101 W
- Voltage - Isolation:2.25 kV
- Applications:ITE (Commercial)
- Features:Remote On/Off
- Operating Temperature:-40°C ~ 85°C (With Derating)
- Efficiency:90%
- Mounting Type:Through Hole
- Package / Case:Quarter Brick
- Size / Dimension:2.43" L x 1.58" W x 0.50" H (61.8mm x 40.2mm x 12.7mm)
- Supplier Device Package:Quarter Brick
- Control Features:-
- Approval Agency:-
- Standard Number:-
