150QBW4_4812S2.25

Technical Details

• Series:150QBW4_2.25 (150W)
• Package:Tube
• Part Status:Active
• Type:Isolated Module
• Number of Outputs:1
• Voltage - Input (Min):18V
• Voltage - Input (Max):75V
• Voltage - Output 1:12V
• Voltage - Output 2:-
• Voltage - Output 3:-
• Voltage - Output 4:-
• Current - Output (Max):12.5A
• Power (Watts):150 W

• Voltage - Isolation:2.25 kV
• Applications:ITE (Commercial)
• Features:Remote Sense
• Operating Temperature:-40°C ~ 85°C (With Derating)
• Efficiency:91%
• Mounting Type:Through Hole
• Package / Case:Quarter Brick
• Size / Dimension:2.43" L x 1.58" W x 0.50" H (61.8mm x 40.2mm x 12.7mm)
• Supplier Device Package:Quarter Brick
• Control Features:-
• Approval Agency:CE
• Standard Number:-
