RDC4072D15

Technical Details

• Series:RDC (40W)
• Package:Tube
• Part Status:Active
• Type:Isolated Module
• Number of Outputs:2
• Voltage - Input (Min):36V
• Voltage - Input (Max):140V
• Voltage - Output 1:15V
• Voltage - Output 2:-15V
• Voltage - Output 3:-
• Voltage - Output 4:-
• Current - Output (Max):1.35A, 1.35A
• Power (Watts):40 W

• Voltage - Isolation:1.5 kV
• Applications:ITE (Commercial), Railway
• Features:Remote On/Off, OCP, OTP, OVP, SCP, UVLO
• Operating Temperature:-40°C ~ 85°C
• Efficiency:88%
• Mounting Type:Through Hole
• Package / Case:6-DIP Module
• Size / Dimension:2.00" L x 1.60" W x 0.42" H (50.8mm x 40.6mm x 10.7mm)
• Supplier Device Package:-
• Control Features:Enable, Active High
• Approval Agency:-
• Standard Number:62368-1
