RDC3072T0315

Technical Details

• Series:RDC (30W)
• Package:Tube
• Part Status:Active
• Type:Isolated Module
• Number of Outputs:3
• Voltage - Input (Min):36V
• Voltage - Input (Max):140V
• Voltage - Output 1:3.3V
• Voltage - Output 2:15V
• Voltage - Output 3:-15V
• Voltage - Output 4:-
• Current - Output (Max):5A, 330mA, 330mA
• Power (Watts):30 W

• Voltage - Isolation:1.5 kV
• Applications:Railway
• Features:Remote On/Off, OCP, OVP, SCP, UVLO
• Operating Temperature:-40°C ~ 75°C
• Efficiency:88%
• Mounting Type:Through Hole
• Package / Case:7-DIP Module
• Size / Dimension:2.00" L x 1.00" W x 0.40" H (50.8mm x 25.4mm x 10.2mm)
• Supplier Device Package:-
• Control Features:Enable, Active High
• Approval Agency:-
• Standard Number:62368-1
