RP100H-2424SRW/P

Technical Details

• Series:POWERLINE RP100-RW (100W)
• Package:Tray
• Part Status:Active
• Type:Isolated Module
• Number of Outputs:1
• Voltage - Input (Min):9V
• Voltage - Input (Max):36V
• Voltage - Output 1:24V
• Voltage - Output 2:-
• Voltage - Output 3:-
• Voltage - Output 4:-
• Current - Output (Max):4.2A
• Power (Watts):100 W

• Voltage - Isolation:2.25 kV
• Applications:ITE (Commercial), Railway
• Features:Remote On/Off, OCP, OTP, OVP, SCP, UVLO
• Operating Temperature:-40°C ~ 105°C (With Derating)
• Efficiency:90%
• Mounting Type:Through Hole
• Package / Case:Half Brick
• Size / Dimension:2.40" L x 2.28" W x 0.48" H (61.0mm x 57.9mm x 12.1mm)
• Supplier Device Package:Half Brick
• Control Features:-
• Approval Agency:-
• Standard Number:-
