RP180H-4812SRW/P-HC

Technical Details

• Series:POWERLINE RP180-RW (180W)
• Package:Tray
• Part Status:Active
• Type:Isolated Module
• Number of Outputs:1
• Voltage - Input (Min):16.5V
• Voltage - Input (Max):75V
• Voltage - Output 1:12V
• Voltage - Output 2:-
• Voltage - Output 3:-
• Voltage - Output 4:-
• Current - Output (Max):13A
• Power (Watts):156 W

• Voltage - Isolation:2.25 kV
• Applications:ITE (Commercial), Railway
• Features:Remote On/Off, OCP, OTP, OVP, SCP, UVLO
• Operating Temperature:-40°C ~ 115°C (With Derating)
• Efficiency:91%
• Mounting Type:Through Hole
• Package / Case:Half Brick
• Size / Dimension:2.40" L x 2.28" W x 0.95" H (61.0mm x 57.9mm x 24.1mm)
• Supplier Device Package:Half Brick
• Control Features:-
• Approval Agency:-
• Standard Number:-
