E1515XT-1WR3

Technical Details

• Series:E1515XT-1WR3 (1W)
• Package:Tube
• Part Status:Active
• Type:Isolated Module
• Number of Outputs:2
• Voltage - Input (Min):13.5V
• Voltage - Input (Max):16.5V
• Voltage - Output 1:15V
• Voltage - Output 2:-15V
• Voltage - Output 3:-
• Voltage - Output 4:-
• Current - Output (Max):34mA, 34mA
• Power (Watts):1 W

• Voltage - Isolation:3 kV
• Applications:ITE (Commercial)
• Features:-
• Operating Temperature:-40°C ~ 105°C (With Derating)
• Efficiency:83%
• Mounting Type:Surface Mount
• Package / Case:10-SMD Module, 6 Leads
• Size / Dimension:0.60" L x 0.33" W x 0.29" H (15.2mm x 8.5mm x 7.3mm)
• Supplier Device Package:-
• Control Features:-
• Approval Agency:CB, CE, cURus, UL
• Standard Number:62368-1
