TMR 1-4823

Technical Details

• Series:TMR 1 (1W)
• Package:Tube
• Part Status:Active
• Type:Isolated Module
• Number of Outputs:2
• Voltage - Input (Min):36V
• Voltage - Input (Max):75V
• Voltage - Output 1:15V
• Voltage - Output 2:-15V
• Voltage - Output 3:-
• Voltage - Output 4:-
• Current - Output (Max):33mA, 33mA
• Power (Watts):990 mW

• Voltage - Isolation:1.5 kV
• Applications:ITE (Commercial)
• Features:OCP, SCP
• Operating Temperature:-40°C ~ 85°C
• Efficiency:79%
• Mounting Type:Through Hole
• Package / Case:6-SIP Module, 5 Leads
• Size / Dimension:0.67" L x 0.30" W x 0.43" H (17.0mm x 7.6mm x 11.0mm)
• Supplier Device Package:Module
• Control Features:-
• Approval Agency:CB, CSA
• Standard Number:-
