TMV 2-1212DHI

Technical Details

• Series:TMV 2HI (2W)
• Package:Tube
• Part Status:Active
• Type:Isolated Module
• Number of Outputs:2
• Voltage - Input (Min):10.8V
• Voltage - Input (Max):13.2V
• Voltage - Output 1:12V
• Voltage - Output 2:-12V
• Voltage - Output 3:-
• Voltage - Output 4:-
• Current - Output (Max):84mA, 84mA
• Power (Watts):2 W

• Voltage - Isolation:5.2 kV
• Applications:ITE (Commercial)
• Features:SCP
• Operating Temperature:-40°C ~ 85°C (With Derating)
• Efficiency:82%
• Mounting Type:Through Hole
• Package / Case:7-SIP Module, 5 Leads
• Size / Dimension:0.77" L x 0.30" W x 0.40" H (19.5mm x 7.5mm x 10.2mm)
• Supplier Device Package:-
• Control Features:-
• Approval Agency:-
• Standard Number:-
