TEL 2-1213

Technical Details

• Series:TEL 2 (2W)
• Package:Tube
• Part Status:Not For New Designs
• Type:Isolated Module
• Number of Outputs:1
• Voltage - Input (Min):9V
• Voltage - Input (Max):18V
• Voltage - Output 1:15V
• Voltage - Output 2:-
• Voltage - Output 3:-
• Voltage - Output 4:-
• Current - Output (Max):135mA
• Power (Watts):2 W

• Voltage - Isolation:1.5 kV
• Applications:ITE (Commercial)
• Features:SCP
• Operating Temperature:-40°C ~ 75°C
• Efficiency:80%
• Mounting Type:Through Hole
• Package / Case:16-DIP Module, 6 Leads
• Size / Dimension:0.94" L x 0.54" W x 0.31" H (23.8mm x 13.7mm x 8.0mm)
• Supplier Device Package:-
• Control Features:-
• Approval Agency:-
• Standard Number:-
