TSV 0512D

Technical Details

• Series:TSV (1W)
• Package:Tube
• Part Status:Not For New Designs
• Type:Isolated Module
• Number of Outputs:2
• Voltage - Input (Min):4.5V
• Voltage - Input (Max):5.5V
• Voltage - Output 1:12V
• Voltage - Output 2:-12V
• Voltage - Output 3:-
• Voltage - Output 4:-
• Current - Output (Max):40mA, 40mA
• Power (Watts):960 mW

• Voltage - Isolation:3 kV
• Applications:ITE (Commercial)
• Features:SCP
• Operating Temperature:-40°C ~ 85°C
• Efficiency:78%
• Mounting Type:Surface Mount
• Package / Case:22-SMD Module, 10 Leads
• Size / Dimension:0.60" L x 0.31" W x 0.27" H (15.2mm x 8.0mm x 7.0mm)
• Supplier Device Package:-
• Control Features:-
• Approval Agency:-
• Standard Number:-
