NTH1209MC

Technical Details

• Series:NTH (2W)
• Package:Tube
• Part Status:Not For New Designs
• Type:Isolated Module
• Number of Outputs:2
• Voltage - Input (Min):10.8V
• Voltage - Input (Max):13.2V
• Voltage - Output 1:9V
• Voltage - Output 2:-9V
• Voltage - Output 3:-
• Voltage - Output 4:-
• Current - Output (Max):111mA, 111mA
• Power (Watts):2 W

• Voltage - Isolation:1 kV
• Applications:ITE (Commercial)
• Features:-
• Operating Temperature:-40°C ~ 85°C
• Efficiency:83%
• Mounting Type:Surface Mount
• Package / Case:26-SMD Module, 12 Leads
• Size / Dimension:0.70" L x 0.50" W x 0.23" H (17.8mm x 12.7mm x 5.8mm)
• Supplier Device Package:-
• Control Features:-
• Approval Agency:-
• Standard Number:-
