PQB3-D5-D5-D
CUI Inc.
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionDC DC CONVERTER +/-5V 3W
- CategoryDC DC Converters
- Datasheet PQB3-D5-D5-D Datasheet
-
ECAD Model
- Share
In Stock: 128
Can ship immediately
Pricing:
- 1$14.128
- 30$14.128
Quote It
Technical Details
- Series:PQB3-D (3W)
- Package:Box
- Part Status:Not For New Designs
- Type:Isolated Module
- Number of Outputs:2
- Voltage - Input (Min):4.5V
- Voltage - Input (Max):9V
- Voltage - Output 1:5V
- Voltage - Output 2:-5V
- Voltage - Output 3:-
- Voltage - Output 4:-
- Current - Output (Max):300mA, 300mA
- Power (Watts):3 W
- Voltage - Isolation:1.5 kV
- Applications:ITE (Commercial)
- Features:OCP, SCP
- Operating Temperature:-40°C ~ 105°C
- Efficiency:75%
- Mounting Type:Through Hole
- Package / Case:24-DIP Module, 10 Leads
- Size / Dimension:1.25" L x 0.80" W x 0.40" H (31.8mm x 20.3mm x 10.2mm)
- Supplier Device Package:-
- Control Features:-
- Approval Agency:EN
- Standard Number:55024; 55032 Class A
