ATA00CC18-L

Technical Details

• Series:ATA (3W)
• Package:Tube
• Part Status:Active
• Type:Isolated Module
• Number of Outputs:2
• Voltage - Input (Min):9V
• Voltage - Input (Max):36V
• Voltage - Output 1:15V
• Voltage - Output 2:-15V
• Voltage - Output 3:-
• Voltage - Output 4:-
• Current - Output (Max):100mA, 100mA
• Power (Watts):3 W

• Voltage - Isolation:1.5 kV
• Applications:ITE (Commercial)
• Features:Remote On/Off, OCP, SCP
• Operating Temperature:-40°C ~ 85°C
• Efficiency:80%
• Mounting Type:Through Hole
• Package / Case:16-DIP Module, 7 Leads
• Size / Dimension:0.94" L x 0.54" W x 0.31" H (23.9mm x 13.7mm x 8.0mm)
• Supplier Device Package:-
• Control Features:-
• Approval Agency:-
• Standard Number:-
