TMR 2-0522WISM

Technical Details

• Series:TMR 2WISM (2W)
• Package:Tube
• Part Status:Active
• Type:Isolated Module
• Number of Outputs:2
• Voltage - Input (Min):4.5V
• Voltage - Input (Max):12V
• Voltage - Output 1:12V
• Voltage - Output 2:-12V
• Voltage - Output 3:-
• Voltage - Output 4:-
• Current - Output (Max):83mA, 83mA
• Power (Watts):2 W

• Voltage - Isolation:1.5 kV
• Applications:ITE (Commercial)
• Features:Remote On/Off, SCP
• Operating Temperature:-40°C ~ 80°C (With Derating)
• Efficiency:83%
• Mounting Type:Surface Mount
• Package / Case:14-SMD Module, 7 Leads
• Size / Dimension:0.75" L x 0.59" W x 0.34" H (19.0mm x 14.9mm x 8.7mm)
• Supplier Device Package:-
• Control Features:-
• Approval Agency:-
• Standard Number:-
