TRN 3-1221

Technical Details

• Series:TRN 3 (3W)
• Package:Tube
• Part Status:Active
• Type:Isolated Module
• Number of Outputs:2
• Voltage - Input (Min):9V
• Voltage - Input (Max):18V
• Voltage - Output 1:5V
• Voltage - Output 2:-5V
• Voltage - Output 3:-
• Voltage - Output 4:-
• Current - Output (Max):300mA, 300mA
• Power (Watts):3 W

• Voltage - Isolation:1.6 kV
• Applications:ITE (Commercial)
• Features:SCP
• Operating Temperature:-40°C ~ 85°C
• Efficiency:78%
• Mounting Type:Through Hole
• Package / Case:5-SIP Module
• Size / Dimension:0.47" L x 0.30" W x 0.43" H (11.9mm x 7.7mm x 11.0mm)
• Supplier Device Package:-
• Control Features:-
• Approval Agency:-
• Standard Number:-
