THI 2-0513M

Technical Details

• Series:THI 2M (2W)
• Package:Tube
• Part Status:Active
• Type:Isolated Module
• Number of Outputs:1
• Voltage - Input (Min):4.5V
• Voltage - Input (Max):5.5V
• Voltage - Output 1:15V
• Voltage - Output 2:-
• Voltage - Output 3:-
• Voltage - Output 4:-
• Current - Output (Max):133mA
• Power (Watts):2 W

• Voltage - Isolation:3 kV
• Applications:ITE (Commercial), Medical
• Features:SCP
• Operating Temperature:-40°C ~ 71°C (With Derating)
• Efficiency:66%
• Mounting Type:Through Hole
• Package / Case:16-DIP Module, 6 Leads
• Size / Dimension:0.94" L x 0.54" W x 0.34" H (23.8mm x 13.7mm x 8.6mm)
• Supplier Device Package:-
• Control Features:-
• Approval Agency:-
• Standard Number:-
