ZTW1R54815

Technical Details

• Series:ZTW (1.5W)
• Package:Box
• Part Status:Active
• Type:Isolated Module
• Number of Outputs:2
• Voltage - Input (Min):36V
• Voltage - Input (Max):72V
• Voltage - Output 1:15V
• Voltage - Output 2:-15V
• Voltage - Output 3:-
• Voltage - Output 4:-
• Current - Output (Max):50mA, 50mA
• Power (Watts):1.5 W

• Voltage - Isolation:500 V
• Applications:ITE (Commercial)
• Features:-
• Operating Temperature:-20°C ~ 71°C (With Derating)
• Efficiency:71%
• Mounting Type:Through Hole
• Package / Case:6-DIP Module
• Size / Dimension:1.10" L x 0.39" W x 0.83" H (28.0mm x 10.0mm x 21.0mm)
• Supplier Device Package:-
• Control Features:-
• Approval Agency:-
• Standard Number:-
