TSR 3-1250A

Technical Details

• Series:TSR-3
• Package:Box
• Part Status:Active
• Type:Linear Regulator Replacement
• Number of Outputs:1
• Voltage - Input (Min):4.5V
• Voltage - Input (Max):14V
• Voltage - Output 1:0.59 ~ 6V
• Voltage - Output 2:-
• Voltage - Output 3:-
• Voltage - Output 4:-
• Current - Output (Max):3A
• Power (Watts):18 W

• Voltage - Isolation:-
• Applications:ITE (Commercial)
• Features:Remote On/Off, SCP
• Operating Temperature:-40°C ~ 85°C (With Derating)
• Efficiency:93%
• Mounting Type:Through Hole
• Package / Case:5-SIP Module
• Size / Dimension:0.61" L x 0.37" W x 0.24" H (15.5mm x 9.4mm x 6.2mm)
• Supplier Device Package:-
• Control Features:-
• Approval Agency:-
• Standard Number:-
