TDR 2-2422WI
TRACO Power
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionDC DC CONVERTER +/-12V 2W
- CategoryDC DC Converters
- Datasheet TDR 2-2422WI Datasheet
-
ECAD Model
- Share
In Stock: 187
Can ship immediately
Pricing:
- 1$25.533
- 10$25.533
Quote It
Technical Details
- Series:TDR 2WI (2W)
- Package:Tube
- Part Status:Active
- Type:Isolated Module
- Number of Outputs:2
- Voltage - Input (Min):9V
- Voltage - Input (Max):36V
- Voltage - Output 1:12V
- Voltage - Output 2:-12V
- Voltage - Output 3:-
- Voltage - Output 4:-
- Current - Output (Max):83mA, 83mA
- Power (Watts):2 W
- Voltage - Isolation:1.6 kV
- Applications:ITE (Commercial)
- Features:Remote On/Off, SCP
- Operating Temperature:-40°C ~ 85°C
- Efficiency:81%
- Mounting Type:Through Hole
- Package / Case:14-DIP Module, 7 Leads
- Size / Dimension:0.74" L x 0.50" W x 0.34" H (18.9mm x 12.8mm x 8.7mm)
- Supplier Device Package:-
- Control Features:-
- Approval Agency:-
- Standard Number:-
