TES 2-0523M

Technical Details

• Series:TES 2M (2W)
• Package:Tube
• Part Status:Active
• Type:Isolated Module
• Number of Outputs:2
• Voltage - Input (Min):4.5V
• Voltage - Input (Max):5.5V
• Voltage - Output 1:15V
• Voltage - Output 2:-15V
• Voltage - Output 3:-
• Voltage - Output 4:-
• Current - Output (Max):66mA, 66mA
• Power (Watts):2 W

• Voltage - Isolation:4 kV
• Applications:ITE (Commercial), Medical
• Features:SCP
• Operating Temperature:-25°C ~ 80°C (With Derating)
• Efficiency:73%
• Mounting Type:Surface Mount
• Package / Case:16-SMD Module, 6 Leads
• Size / Dimension:0.94" L x 0.54" W x 0.36" H (24.0mm x 13.7mm x 9.3mm)
• Supplier Device Package:-
• Control Features:-
• Approval Agency:-
• Standard Number:-
