THL 6-4812WISM

Technical Details

• Series:THL 6WISM (6W)
• Package:Tube
• Part Status:Not For New Designs
• Type:Isolated Module
• Number of Outputs:1
• Voltage - Input (Min):18V
• Voltage - Input (Max):75V
• Voltage - Output 1:12V
• Voltage - Output 2:-
• Voltage - Output 3:-
• Voltage - Output 4:-
• Current - Output (Max):500mA
• Power (Watts):6 W

• Voltage - Isolation:1.5 kV
• Applications:ITE (Commercial)
• Features:Remote On/Off, SCP
• Operating Temperature:-40°C ~ 75°C (With Derating)
• Efficiency:83%
• Mounting Type:Surface Mount
• Package / Case:16-SMD Module, 7 Leads
• Size / Dimension:0.87" L x 0.80" W x 0.40" H (22.0mm x 20.3mm x 10.2mm)
• Supplier Device Package:-
• Control Features:-
• Approval Agency:-
• Standard Number:-
