TDR 3-2413WISM

Technical Details

• Series:TDR 3WISM (3W)
• Package:Tube
• Part Status:Active
• Type:Isolated Module
• Number of Outputs:1
• Voltage - Input (Min):9V
• Voltage - Input (Max):36V
• Voltage - Output 1:15V
• Voltage - Output 2:-
• Voltage - Output 3:-
• Voltage - Output 4:-
• Current - Output (Max):200mA
• Power (Watts):3 W

• Voltage - Isolation:1.6 kV
• Applications:ITE (Commercial)
• Features:Remote On/Off, SCP
• Operating Temperature:-40°C ~ 85°C
• Efficiency:82%
• Mounting Type:Surface Mount
• Package / Case:14-SMD Module, 7 Leads
• Size / Dimension:0.74" L x 0.50" W x 0.34" H (18.9mm x 12.8mm x 8.7mm)
• Supplier Device Package:-
• Control Features:-
• Approval Agency:-
• Standard Number:-
