NCS12D4812C

Technical Details

• Series:NCS12 (12W)
• Package:Tube
• Part Status:Active
• Type:Isolated Module
• Number of Outputs:2
• Voltage - Input (Min):18V
• Voltage - Input (Max):75V
• Voltage - Output 1:12V
• Voltage - Output 2:-12V
• Voltage - Output 3:-
• Voltage - Output 4:-
• Current - Output (Max):500mA, 500mA
• Power (Watts):12 W

• Voltage - Isolation:1.5 kV
• Applications:ITE (Commercial)
• Features:OTP, SCP, UVLO
• Operating Temperature:-40°C ~ 85°C
• Efficiency:85%
• Mounting Type:Through Hole
• Package / Case:24-DIP Module, 9 Leads
• Size / Dimension:1.26" L x 0.79" W x 0.41" H (32.0mm x 20.0mm x 10.5mm)
• Supplier Device Package:-
• Control Features:-
• Approval Agency:-
• Standard Number:-
