ULS-3.3/20-D48NH-C

Technical Details

• Series:ULS (60W)
• Package:Tray
• Part Status:Active
• Type:Isolated Module
• Number of Outputs:1
• Voltage - Input (Min):36V
• Voltage - Input (Max):75V
• Voltage - Output 1:3.3V
• Voltage - Output 2:-
• Voltage - Output 3:-
• Voltage - Output 4:-
• Current - Output (Max):20A
• Power (Watts):66 W

• Voltage - Isolation:2.25 kV
• Applications:ITE (Commercial)
• Features:Remote On/Off, OTP, OVP, SCP, UVLO
• Operating Temperature:-40°C ~ 85°C
• Efficiency:90%
• Mounting Type:Through Hole
• Package / Case:8-DIP Module, 1/16 Brick
• Size / Dimension:1.30" L x 0.90" W x 0.40" H (33.0mm x 22.9mm x 10.2mm)
• Supplier Device Package:-
• Control Features:Enable, Active Low
• Approval Agency:-
• Standard Number:-
