TES 3-4822WI

Technical Details

• Series:TES 3WI (3W)
• Package:Tube
• Part Status:Active
• Type:Isolated Module
• Number of Outputs:2
• Voltage - Input (Min):18V
• Voltage - Input (Max):75V
• Voltage - Output 1:12V
• Voltage - Output 2:-12V
• Voltage - Output 3:-
• Voltage - Output 4:-
• Current - Output (Max):125mA, 125mA
• Power (Watts):3 W

• Voltage - Isolation:1.5 kV
• Applications:ITE (Commercial)
• Features:Remote On/Off, SCP
• Operating Temperature:-40°C ~ 71°C
• Efficiency:83%
• Mounting Type:Surface Mount
• Package / Case:24-SMD Module, 12 Leads
• Size / Dimension:1.27" L x 0.58" W x 0.40" H (32.2mm x 14.8mm x 10.2mm)
• Supplier Device Package:-
• Control Features:-
• Approval Agency:-
• Standard Number:-
