EC7A-24D15S

Technical Details

• Series:EC7A (10W)
• Package:Tube
• Part Status:Active
• Type:Isolated Module
• Number of Outputs:2
• Voltage - Input (Min):18V
• Voltage - Input (Max):36V
• Voltage - Output 1:15V
• Voltage - Output 2:-15V
• Voltage - Output 3:-
• Voltage - Output 4:-
• Current - Output (Max):333mA, 333mA
• Power (Watts):10 W

• Voltage - Isolation:1.5 kV
• Applications:ITE (Commercial)
• Features:OCP, OVP, SCP, UVLO
• Operating Temperature:-40°C ~ 85°C (With Derating)
• Efficiency:87%
• Mounting Type:Surface Mount
• Package / Case:24-SMD Module, 18 Leads
• Size / Dimension:1.25" L x 0.80" W x 0.45" H (31.8mm x 20.3mm x 11.4mm)
• Supplier Device Package:-
• Control Features:-
• Approval Agency:-
• Standard Number:-
