PKB5113WPI

Technical Details

• Series:PKB5000W (120W)
• Package:Tray
• Part Status:Last Time Buy
• Type:Isolated Module
• Number of Outputs:1
• Voltage - Input (Min):18V
• Voltage - Input (Max):75V
• Voltage - Output 1:12V
• Voltage - Output 2:-
• Voltage - Output 3:-
• Voltage - Output 4:-
• Current - Output (Max):10A
• Power (Watts):120 W

• Voltage - Isolation:2.25 kV
• Applications:ITE (Commercial)
• Features:Adjustable Output, Remote On/Off, Remote Sense
• Operating Temperature:-40°C ~ 110°C (With Derating)
• Efficiency:91.5%
• Mounting Type:Through Hole
• Package / Case:Eighth Brick
• Size / Dimension:2.30" L x 0.90" W x 0.39" H (58.4mm x 22.9mm x 9.9mm)
• Supplier Device Package:Eighth Brick
• Control Features:Enable, Active Low
• Approval Agency:CB, CSA, IEC, TUV, UL
• Standard Number:62368-1
